Most heat trace system maintenance happens in the fall — before the heating season begins — or in the spring, after it ends. However, the team at FloTrace knows that the period when a system is most stressed, and when failures are most likely to occur, is mid-season: during extended cold snaps, freeze-thaw cycles, and the accumulated wear of continuous winter operation.
A mid-season audit — a structured review of system performance conducted during the heating season — allows facility managers and property owners to identify developing problems before they become full failures. This guide provides a practical framework for conducting that audit.
When to Conduct a Mid-Season Audit
The ideal time for a mid-season audit is during a period when the system has been under load for several weeks but is not currently in an emergency weather event. For most northern-climate installations, January or early February is appropriate. The system has been operating for months, any early-season problems have been identified, and there is still time to contact a heat trace supplier for replacement parts before the season's most demanding conditions.
If your location experiences a particularly severe cold snap early in the season, conduct the audit shortly afterward — extreme cold events stress heat trace products and often reveal latent problems.
Part 1: Visual Inspection Checklist
Roof and Gutter Systems
- Verify the heat trace cable is visible and in place in all gutter troughs.
- Check for ice dams at downspout connections — indicates a blocked or non-functioning section.
- Inspect visible cable sections for physical damage (damage from ice loading, foot traffic, or wildlife).
- Confirm heat trace for gutters is allowing downspouts to drain; standing ice indicates a failed section.
- Look for icicle formation at eave edges — significant icicles indicate the eave cable section is not functioning.
Pipe Trace Systems
- Inspect exposed pipe heating cable in accessible locations for physical damage.
- Check that pipe insulation jacketing is intact at all inspection points.
- Look for frost or condensation on pipe surfaces that should be protected — indicates cable underperformance.
- Check heat trace system components, such as junction boxes, for moisture accumulation.
- Verify that insulation is intact at all valve bodies and fittings.
Electrical and Controls
- Confirm all circuit breakers are in the ON position.
- Check that no GFCI devices have tripped.
- Verify the control panel (if installed) shows no fault or alarm conditions.
- For thermostatic systems, confirm that the thermostats are set to the appropriate setpoints.
Part 2: Electrical Performance Checks
Visual inspection identifies obvious physical problems, but many developing failures are invisible until they show up in electrical measurements. For critical circuits, perform these checks:
Current draw verification
Use a clamp meter to measure the current draw of each circuit. Compare the measured current to the expected current for the cable type, such as a self-regulating heat trace cable. Significant deviations indicate problems:
- Lower current than expected — may indicate a broken wire or failed heat trace components.
-
Higher current than expected — may indicate polymer aging or a cable in water immersion.
Ground fault check
Test GFCI devices by pressing the TEST button — the breaker should trip. Press RESET to restore power. Any GFCI that does not trip when tested has a failed test mechanism and should be replaced.
Part 3: Performance Verification
Beyond electrical checks, verify that the system is actually achieving its protective purpose:
- Check pipe surface temperatures in accessible locations — use an infrared thermometer or contact thermometer to verify that traced pipes are above their design maintenance temperature — readings near or below the freeze point indicate inadequate performance
- Verify gutter drainage during melt periods — after a snow event, observe gutters and downspouts during the melt phase — water should drain freely, not back up or freeze
- Check for new ice dam formation — observe roof eaves after snow events and compare to pre-installation performance — new ice dam formation in areas that were previously protected indicates a performance problem
Part 4: Documenting Findings and Taking Action
The mid-season audit is only useful if findings are documented and acted upon. For each circuit and installation area:
- Record visual condition — any physical damage or anomalies observed
- Record electrical measurements — current draw and any GFCI or control panel findings
- Rate overall circuit condition — performing normally, needs monitoring, or requires repair
- Prioritize repairs — address any circuits protecting critical systems (fire suppression, domestic water, process piping) before circuits with a lower consequence of failure
-
Schedule any required repairs — if weather permits, make repairs promptly; if not, plan for repair at the first available opportunity
Repair or Monitor? A Decision Framework
Not every anomaly found in a mid-season audit requires immediate repair. Use this framework to prioritize:
- Repair immediately — any circuit protecting fire suppression, any circuit showing zero current, or any self regulating heat trace cable with a damaged outer jacket.
- Repair at first opportunity — circuits with declining insulation resistance or a GFCI that is tripping repeatedly.
-
Monitor through the end of the season — circuits with minor current deviations that are still clearly protecting their pipes, cables with minor jacket discoloration that are otherwise functioning.
Don't let your freeze protection become a source of winter stress. A mid-season audit ensures your system is ready to perform under pressure. At FloTrace, we’re committed to providing the self-regulating heat trace solutions and expertise you need to stay ahead of the weather and operate with confidence.
Have a question or need help with your mid-season audit, contact us our team is ready to help.
